Built for uninterrupted ultra-wide production.
The Signature 5 Meter platform is engineered for industrial-scale roll-to-roll printing environments where production continuity, color consistency, and long-term reliability are critical. Designed for demanding high-volume workflows, the system combines precision media handling with advanced motion control to deliver stable performance across ultra-wide applications.
Developed around industrial production principles, the Signature 5 Meter supports continuous operation while maintaining exceptional output quality over extended production cycles. From high-speed banner production to premium visual communication applications, every subsystem is optimized for efficient, large-scale manufacturing environments.
Engineering Philosophy
Three core principles define the Signature 5 Meter platform:
Ultra-Wide Production Stability — optimized tension control, precision feeding systems, and stable carriage dynamics for consistent results across 5-meter media widths.
Continuous Industrial Operation — engineered for demanding multi-shift workflows with reliable system architecture and production-focused durability.
Intelligent Workflow Efficiency — advanced control systems and responsive production management designed to maximize uptime and operational consistency.
Application Range
The Signature 5 Meter series is developed for industrial roll production environments including:
- Superwide signage and billboard production
- Backlit and frontlit applications
- Fleet graphics and large-scale advertising
- Exhibition and event graphics
- Premium visual communication projects
Color Performance
Supporting advanced color configurations including CMYK, White, and Varnish options, the Signature 5 Meter platform delivers strong color density, smooth gradients, enhanced surface effects, and consistent image quality across ultra-wide production applications.
Industrial Service Architecture
Every Signature 5 Meter system is backed by Platinum’s global technical support structure, including preventive maintenance programs, certified technical assistance, remote diagnostics, and worldwide spare-part accessibility.
The Signature 5 Meter is engineered not for showroom presentation, but for real industrial production environments where uptime, consistency, and dependable large-scale output define performance.
Technical Specifications
| Print Resulation | 2400 DPI |
| Print With | 5000 mm |
| Print Speed Up to | 500 m²/h |
| Print Head | Ricoh Gen6 |
| Ink Type | UV - LED |
| Drop Volume | 5 Pl. |
| Power Requirements | 380v (±10%) / 3x32A / 50 Hz |
| Drying System | LED |
| Machine Weight | 6200 kg |
| Floor Area | 2100x8730x2430mm |
| Color Scale | CMYK + LcLm + W + V + Neon Color |
| RIP | Photo Print / Caldera (Opt.) |
