Specifications

  • Up to 2400 dpi print resolution
  • 5 pL droplet size
  • White and Varnish printing options
  • Automatic head cleaning unit
  • Dual-direction automatic material loading
  • Continuous printing system
Platinum Q3XL+ UV Hybrid Brochure Book a Demo
Menu background

Book a Demo

See the latest print and finishing technology up close and personal. At our Altham demonstration centre, you’ll get hands-on with leading wide-format printers, cutters, and media.
Whether you're exploring new hardware or testing specific materials, our expert team will guide you through a tailored session that’s focused on your business needs.

Enquire about this product
Menu background

Enquire about this product

If you want to enquire about this product, please fill in the form and we will get back to you as soon as possible.

1
2
3
  • 1

    Enhanced with 4 print zones and 4 vacuum motors, helping provide stable material handling and efficient operation during production.

  • 2

    With a maximum print resolution of 2400 dpi and ultra-fine 5 picolitre droplet technology, the Platinum Q3XL Hybrid is designed to deliver sharp detail, smooth gradients and vibrant colour reproduction across a wide range of applications.

  • 3

    The AutoClean system activates during potential printhead clogs, providing contact-free cleaning. It saves time, simplifies maintenance, and supports uninterrupted production.

Advance Hybrid UV Printer for Versatile Production

The Platinum Q3XL UV Hybrid brings together advanced UV printing technology, high-resolution output and production-focused automation in a single hybrid platform. Designed to support a wide range of applications, the system is capable of producing high-quality prints across a variety of commonly used rigid and flexible materials.
Built for demanding production environments, the Platinum Q3XL Hybrid combines precision print performance with features designed to improve workflow efficiency, reduce downtime and support consistent day-to-day operation.

Built for High-Quality Output

With a maximum print resolution of 2400 dpi and ultra-fine 5 picolitre droplet technology, the Platinum Q3XL Hybrid
is designed to deliver sharp detail, smooth gradients and vibrant colour reproduction across a wide range of applications.

The system also supports White and Varnish printing options, providing additional flexibility for creative and specialist print work.

Production-Focused Automation

The Platinum Q3XL Hybrid is equipped with a range of automation features designed to support efficient and reliable production, including:

  • Automatic head cleaning unit
  • Dual-direction automatic material loading and operation
  • Continuous printing system
  • Antistatic system
  • Automatic material height measurement system

Together, these features help streamline workflow, minimise manual intervention and support uninterrupted production throughout longer print runs.

Designed for Flexible Media Handling

Capable of printing onto materials up to 5 cm thick, the Platinum Q3XL Hybrid is built to handle a broad range of applications and substrate types.

The machine is further enhanced with 4 print zones and 4 vacuum motors, helping provide stable material handling and efficient operation during production.

Print Heads Ricoh Gen6
Print Resolution 2400 DPI
Print Head Drop Volume Gen6 5Pl.
Printhead Quantity 32 (Max.)
Ink Config CMYK+LcLm+W+V+Neon Colors
Ink Curing Type UV - LED
Print Speed Up to 250 m2/h
Max Media Thickness 50 mm
Print Width 3200mm
Machine Weight 3500 kg.
Machine Power Requirements 230v (+/-) 10% / 40A / 50HZ / 60HZ
